Gearbox model: 12JS160T
Brand: FAST
Series: 12 block series
Block a number: 12 block
Product Features: Double intermediate shaft, power shunt, unique structure; Full synchronizer, main box is double conical surface lock ring synchronizer, with large synchronous capacity; The auxiliary box is an enhanced locking pin type inertial synchronizer with non-metallic friction material and high reliability
Matching range: The gearbox with a retarder is suitable for trucks, special vehicles and other vehicles that often run downhill or brake frequently.
Forward gear: 12 block
Reverse gear number: 2Pcs
Shifting mode: manual
Maximum input torque: 2000N.m
Rated speed: 2600rpm
Whether there is a synchronizer: OK
Head gear ratio: 15.53
2 gear ratio: 12.08
3 gear transmission ratio: 9.39
4 gear transmission ratio: 7.33
5 gear ratio: 5.73
6 gear transmission ratio: 4.46
7 gear ratio: 3.48
8 gear ratio: 2.71
9 gear transmission ratio: 2.1
10 gear ratio: 1.64
11 Gear ratio: 1.28
12 gear ratio: 1
Reverse 1 transmission ratio: 14.86
Reverse 2 transmission ratio: 3.33
Gearbox weight: 350kg
Transmission oil capacity: 14.5L
Mode of operation: Single, double lever control, left, right control and two way control
